Datalogic Gryphon I GD4500

Tuote

Valmistaja

Datalogic

Tuotenimi

Gryphon I GD4500

Valmistajan linkki

http://www.datalogic.com/eng/products/manufacturing-healthcare..

Tuotekoodit

Valmistajan tuotekoodit

• GD4590-BK-B

GTIN- / EAN-koodit

• 0889728089937
• 0993274950709

Tuotekuvat

Scanning

Type

Handheld bar code reader

Scanner type

1D/2D

Linear (1D) barcodes supported

Code 39, EAN-13, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, PDF417, Planet, POSTNET, U.P.C.

2D (matrix & stacked) barcodes supported

Aztec Code, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code

Optical sensor resolution (W x H)

1280 x 800 pixels

Light levels (direct sunlight)

0 - 100000 lx

Wavelength

650 nm

Tilt reading angle

0 - 360 °

Pitch reading angle

-65 - 65 °

Yaw reading angle

-65 - 65 °

Motion tolerance (cm/s)

88.9

Ports & interfaces

Connectivity technology

Wired

Standard interfaces

RS-232, USB, Keyboard wedge

Performance

Product colour

Black

International Protection (IP) code

IP52

Protection features

Shock resistant

Built-in display

Ei

Image formats supported

BMP, JPEG

Certification

IEC 60825 Class 2

Power

Power source type

DC

Input voltage

4.5 - 14 V

Power consumption

300 mA

Weight & dimensions

Width

68 mm

Depth

109 mm

Height

166 mm

Weight

161 g

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Storage temperature (T-T)

-40 - 70 °C

Operating relative humidity (H-H)

0 - 95 %

Technical details

Compliance certificates

RoHS

Logistics data

Harmonized System (HS) code

84716070
