ZyXEL GS1920-24V2

Tuote

Valmistaja

ZyXEL

Tuotenimi

GS1920-24V2

Valmistajan linkki

https://www.zyxel.com/products_services/8-24-48-port-GbE-Smart..

Tuotekoodit

Valmistajan tuotekoodit

• GS1920-24V2-EU0101F

Tuotekuvat

Management features

Switch type

Managed

Quality of Service (QoS) support

Kyllä

ARP inspection

Kyllä

System event log

Kyllä

MIB support

RFC 1066, RFC 1213, RFC 1157, RFC 1493, RFC 1643, RFC 1757, RFC 2011.2012,2013, RFC 2233, RFC 2358, RFC 2674, RFC 2819,2925, RFC 3621, RFC 4022, RFC 4113, RFC 4292, RFC 4293

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity

24

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

Installed SFP modules quantity

0

Installed SFP+ modules quantity

0

Combo SFP ports quantity

4

Fiber optic connector

SFP

Network

Networking standards

IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

10G support

Ei

Copper ethernet cabling technology

100BASE-TX, 1000BASE-T

Flow control support

Kyllä

Rate limiting

Kyllä

Spanning tree protocol

Kyllä

VLAN support

Kyllä

Virtual LAN features

Private VLAN, Voice VLAN, Protocol-based VLAN, MAC address-based VLAN, Port-based VLAN, IP subnet–based VLAN

Optical fiber

Fiber ethernet cabling technology

1000BASE-X

Data transmission

MAC address table

16000 entries

Switching capacity

56 Gbit/s

Forwarding rate

42 Mpps

Packet buffer memory

1.5 MB

Security

DHCP features

DHCP snooping, DHCP relay, DHCPv6 relay, DHCP client

Access Control List (ACL)

Kyllä

IGMP snooping

Kyllä

Security algorithms

802.1x RADIUS, SNMP, SNMPv3

MAC address filtering

Kyllä

IP-MAC-Port binding

Kyllä

Authentication

Guest VLAN, Port-based authentication

Password protection

Kyllä

Authentication type

IEEE 802.1x, RADIUS

CPU defense

Kyllä

Queue scheduling algorithms

SPQ, WFQ, Weighted Round Robin (WRR)

Multicast features

Multicast support

Kyllä

Design

Rack mounting

Kyllä

Product colour

Black

LED indicators

Kyllä

Safety

LVD, BSMI

Electromagnetic compatibility

FCC 15 A, CE A, BSMI EMC

Performance

Internal memory

256 MB

Flash memory

32 MB

Noise level

0 dB

Mean time between failures (MTBF)

911301 h

Power

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Power consumption (max)

22.5 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)

Ei

Operational conditions

Operating temperature (T-T)

0 - 50 °C

Storage temperature (T-T)

-40 - 70 °C

Operating relative humidity (H-H)

10 - 95 %

Storage relative humidity (H-H)

10 - 95 %

Heat dissipation

76.73 BTU/h

Weight & dimensions

Width

441 mm

Depth

131 mm

Height

44 mm

Weight

2100 g

Packaging content

Cables included

AC

Rack mount kit

Kyllä

Packaging data

Package width

558 mm

Package depth

214 mm

Package height

79 mm

Package weight

2910 g

Certificates

Certification

RoHS

Logistics data

Harmonized System (HS) code

85176990
