Synology RackStation RS1619XS+

Tuote

Valmistaja

Synology

Tuoteperhe / -sarja

RackStation

Tuotenimi

RS1619XS+

Valmistajan linkki

https://www.synology.com

Tuotekoodit

Valmistajan tuotekoodit

• RS1619XS+

GTIN- / EAN-koodit

• 0846504003068
• 4711174723065

Tuotekuvat

Storage

Storage drives installed

Ei

Total installed storage capacity

0 TB

Number of storage drives installed

0

Number of storage drives supported

4

Installed storage drive type

Ei

Supported storage drive types

HDD & SSD

Storage drive capacity

0 GB

Storage drive interface

Serial ATA, Serial ATA II, Serial ATA III

Storage drive sizes supported

2.5,3.5 "

Number of M.2 (M & B) slots

2

RAID support

Kyllä

RAID levels

0, 1, 5, 6, 10, JBOD

Hot-swap drive bays

Kyllä

Supported file systems

BTRFS, Fat, HFS+, NTFS, ext3, ext4

Processor

Processor manufacturer

Intel

Processor family

Intel® Xeon® D

Processor model

D-1527

Processor frequency

2.2 GHz

Processor boost frequency

2.7 GHz

Processor cores

4

Processor threads

8

Processor cache

6 MB

CPU configuration (max)

1

ECC supported by processor

Kyllä

PCI Express configurations

1x16, 1x4, 1x8

PCI Express slots version

2.0, 3.0

Processor cache type

L3

Processor code

SR2DK

Processor codename

Broadwell

Processor lithography

14 nm

Processor operating modes

64-bit

Processor package size

37.5 x 37.5 mm

Processor series

Intel Xeon D-1500

Processor socket

BGA 1667

Scalability

1S

Stepping

V2

Thermal Design Power (TDP)

35 W

On-board graphics card model

Not available

Maximum internal memory supported by processor

128 GB

Conflict-Free processor

Kyllä

Memory

Internal memory

8 GB

Internal memory type

DDR4

Maximum RAM supported

64 GB

Memory slots

4

Network

Ethernet LAN

Kyllä

Ethernet LAN data rates

10,100,1000 Mbit/s

Wi-Fi

Ei

iSCSI support

Kyllä

Wake-on-LAN ready

Kyllä

Supported network protocols

CIFS, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN, L2TP)

Link aggregation

Kyllä

Ports & interfaces

Ethernet LAN (RJ-45) ports

4

USB port

Kyllä

USB 2.0 ports quantity

0

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

Fiber ports quantity

0

Expansion ports quantity

1

PCI Express x8 (Gen 3.x) slots

1

Design

Chassis type

Rack (1U)

Cooling type

Active

Product colour

Black

Number of fans

2 fan(s)

Fan diameter

40 mm

LED indicators

Alarm, HDD, Power, Status

Performance

Type

NAS

Device class

Small & Medium Business

Backup function

Kyllä

Backup features

Cloud, iSCSI LUN

Multilingual support

Kyllä

Noise level

39.3 dB

Web-based management

Kyllä

Security algorithms

HTTPS, SSH, SSL/TLS

Access Control List (ACL)

Kyllä

Reset button

Kyllä

On/off switch

Kyllä

Browser supported

Chrome, Firefox, Internet Explorer 10+, Safari 10+

Software

Operating system installed

DiskStation Manager

Windows operating systems supported

Windows 10, Windows 7

Mac operating systems supported

Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave

Server operating systems supported

Windows Server 2016

Power

Power supply location

Built-in

Power supply unit (PSU) capacity

150 W

Number of power supply units

2

Power consumption (typical)

68.68 W

Power consumption (HDD standby)

34.78 W

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Weight & dimensions

Width

480 mm

Depth

518.6 mm

Height

44 mm

Weight

8160 g

Packaging content

Cables included

AC

Quick installation guide

Kyllä

Processor special features

Embedded options available

Kyllä

Enhanced Intel SpeedStep Technology

Kyllä

Execute Disable Bit

Kyllä

Idle States

Kyllä

Intel 64

Kyllä

Intel Enhanced Halt State

Kyllä

Intel Secure Key Technology version

1.00

Intel Trusted Execution Technology

Kyllä

Intel TSX-NI

Kyllä

Intel TSX-NI version

1.00

Intel Virtualization Technology (VT-x)

Kyllä

Intel Virtualization Technology for Directed I/O (VT-d)

Kyllä

Intel VT-x with Extended Page Tables (EPT)

Kyllä

Intel® AES New Instructions (Intel® AES-NI)

Kyllä

Intel® Hyper Threading Technology (Intel® HT Technology)

Kyllä

Intel® OS Guard

Kyllä

Intel® Secure Key

Kyllä

Intel® Turbo Boost Technology

2.0

Maximum number of PCI Express lanes

32

Thermal Monitoring Technologies

Kyllä

UART

Kyllä

Memory channels supported by processor

Dual

Memory types supported by processor

DDR3-SDRAM, DDR4-SDRAM

Operational conditions

Operating temperature (T-T)

5 - 35 °C

Operating relative humidity (H-H)

5 - 95 %

Storage temperature (T-T)

-20 - 60 °C

Operating altitude

0 - 5000 m

Logistics data

Harmonized System (HS) code

84714100

Other features

Compliance certificates

RoHS

Certification

EAC VCCI RCM FCC CE BSMI

Processor ARK ID

91195
