Huawei B311-221 LTE White

Tuote

Valmistaja

Huawei

Tuotenimi

B311-221 LTE White

Valmistajan linkki

https://www.huawei.com/

Tuotekoodit

Valmistajan tuotekoodit

• 51060DWA

GTIN- / EAN-koodit

• 6901443320592

Tuotekuvat

WAN connection

Ethernet WAN

Kyllä

DSL WAN

Ei

SIM card slot

Kyllä

3G/4G USB modem compatibility

Kyllä

WAN connection type

RJ-45

Wireless LAN features

Wi-Fi band

Single-band (2.4 GHz)

Top Wi-Fi standard

Wi-Fi 4 (802.11n)

WLAN data transfer rate (max)

300 Mbit/s

Wi-Fi standards

802.11b, 802.11g, Wi-Fi 4 (802.11n)

Network

Ethernet LAN

Kyllä

Ethernet LAN interface type

Gigabit Ethernet

Ethernet LAN data rates

10,100,1000 Mbit/s

Networking standards

IEEE 802.3, IEEE 802.3u

Port forwarding

Kyllä

Port triggering

Kyllä

VPN support

L2TP VPN client PPTP VPN client

Mobile network

Mobile network generation

4G

2G standards

Edge, GPRS

3G standards

DC-HSPA+, HSPA, HSPA+, WCDMA

4G standard

LTE-FDD

GSM bands supported

2600,850,900,1800,1900 MHz

4G bands supported

800,900,1800,2100,2600 MHz

SIM card type

MiniSIM

Short Message Service (SMS)

Kyllä

Ports & interfaces

Ethernet LAN (RJ-45) ports

1

Management features

Wi-Fi Multimedia (WMM)/(WME)

Kyllä

Reset button

Kyllä

WPS push button

Kyllä

MIMO

Kyllä

Number of data streams

2x2

Security

Security algorithms

64-bit WEP, 128-bit WEP, AES, TKIP, WEP, WPA-PSK, WPA2

MAC address filtering

Kyllä

IP address filtering

Kyllä

URL filtering

Kyllä

DMZ support

Kyllä

Network address translation (NAT)

Kyllä

Protocols

DHCP server

Kyllä

Universal Plug and Play (UPnP)

Kyllä

Voice codecs

G.711a, G.711u, G.722, G.726, G.726-32, G.729

Design

Product type

Tabletop router

Product colour

White

LED indicators

Power, Status, WAN, WLAN

On/off switch

Kyllä

Antenna

Antenna design

Internal

Antenna gain level (max)

3.8 dBi

Antennas quantity

2

Power

Power source type

AC

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Output voltage

12 V

Output current

1 A

Power consumption (typical)

12 W

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Storage temperature (T-T)

-20 - 70 °C

Operating relative humidity (H-H)

5 - 95 %

System requirements

Mac operating systems supported

Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.9 Mavericks

Weight & dimensions

Width

186 mm

Depth

139 mm

Height

46 mm

Weight

218 g
