Ominaisuudet
- Malli
- IP-turvakamera
- Tuettu sijoitus
- Sisätila
- Yhteysteknologia
- Langallinen
- Kiinnitystyyppi
- Katto/seinä
- Tuotteen väri
- Musta, Valkoinen
- Anturin tyyppi
- CMOS
Arvostelut
Arvostele tuoteAlin hinta 30 päivän aikana
4 401,15 €
+5,19 %
Hinta on nyt 228,40 € kalliimpi.
HintahistoriaTuotetiedot
Tuote
- Valmistaja
- Axis
- Tuotenimi
- 02022-002
- Julkaisupäivä
- 04.03.2021
- Valmistajan linkki
- https://www.axis.com/products/axis-v5938
Tuotekoodit
- Valmistajan tuotekoodit
- 02022-002
- GTIN- / EAN-koodit
- 7331021070868
Tuotekuvat
Performance
- Type
- IP security camera
- Placement supported
- Indoor
- Connectivity technology
- Wired
- PTZ control
- Kyllä
- Preset points
- Kyllä
- Day/night mode
- Kyllä
- Certification
- EN 55032 Class A, EN 55024, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A, CISPR 24, CISPR 35, KC KN32 Class A, KC KN35, IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, KC-Mark, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, NIST SP500-267
Design
- Mounting type
- Ceiling/wall
- Product colour
- Black, White
- Housing material
- Plastic
- Fog proof
- Kyllä
Camera
- Minimum illumination
- 0.1 lx
- Lens viewing angle, horizontal
- 70.2 °
- Lens viewing angle, vertical
- 39.5 °
- Tilt angle range
- -20 - 90 °
- Tilt speed
- 90 °/sec
- Pan range
- -170 - 170 °
- Pan speed
- 100 °/sec
- Camera shutter speed
- 1/10000 - 1 s
Image sensor
- Sensor type
- CMOS
- Number of sensors
- 1
- Optical sensor size
- 1/2.5 "
- Progressive scan
- Kyllä
Lens system
- Number of lenses
- 1
- Zoom capability
- Kyllä
- Optical zoom
- 20 x
- Digital zoom
- 12 x
- Focal length range
- 4.4 - 88 mm
- Auto focus
- Kyllä
- Maximum aperture number
- 3.8
- Minimum aperture number
- 2
Video
- Maximum resolution
- 3840 x 2160 pixels
- Video formats supported
- AVC, H.264, H.265, HEVC, M-JPEG, MPEG4
- Supported video modes
- 2160p
- Frame rate
- 60 fps
- Video streaming
- Kyllä
- Noise reduction
- Kyllä
- Image quality adjustment
- Brightness, Sharpness
- Image stabilizer
- Kyllä
- Back Light Compensation (BLC)
- Kyllä
Audio
- Audio system
- 2-way
- Audio formats supported
- ADPCM, G.711, G.726, LPCM, PCM
- Sample rate
- 48 kHz
- Audio detection
- Kyllä
Network
- Ethernet LAN
- Kyllä
- Ethernet interface type
- Fast Ethernet, Gigabit Ethernet
- Networking standards
- IEEE 802.1x
- Supported network protocols
- IPv4/v6, HTTP, HTTP/2, HTTPS , SSL/TLS , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCPv4/v6, ARP, SOCKS, SSH, SIP, LLDP, MQTT, Syslog
- Quality of Service (QoS) support
- Kyllä
- Streaming method
- Multicast
Storage
- Compatible memory cards
- MicroSD (TransFlash), MicroSDHC, MicroSDXC
- Flash memory
- 512 MB
Ports & interfaces
- Ethernet LAN (RJ-45) ports
- 1
- RS-232 ports
- 1
- Microphone in
- Kyllä
- HDMI ports quantity
- 1
- Terminal block port
- Kyllä
- DC-in jack
- Kyllä
Security
- Password protection
- Kyllä
- IP address filtering
- Kyllä
- HTTPS encryption
- Kyllä
- Pixel counter
- Kyllä
- Digest authentication
- Kyllä
Power
- Power source type
- DC
- Power consumption (typical)
- 17.5 W
- Power consumption (max)
- 20 W
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -40 - 65 °C
- Operating relative humidity (H-H)
- 10 - 85 %
- Storage relative humidity (H-H)
- 5 - 95 %
Weight & dimensions
- Width
- 136 mm
- Depth
- 136 mm
- Height
- 180 mm
- Weight
- 1500 g
Packaging content
- Number of cameras
- 1
- Mounting kit
- Kyllä
- Manual
- Kyllä
Logistics data
- Harmonized System (HS) code
- 85258900
