Be-Quiet System Power 10

Tuote

Valmistaja

Be-Quiet

Tuotenimi

System Power 10

Valmistajan linkki

https://www.bequiet.com/en/powersupply/3926

Tuotekoodit

Valmistajan tuotekoodit

• BN330

GTIN- / EAN-koodit

• 4260052189108

Tuotekuvat

Power

Total power

850 W

AC input voltage

200 - 240 V

AC input frequency

50 Hz

Input current

5 A

Power factor

0.97

Power Factor Correction (PFC) type

Active

Combined power (+3.3V)

120 W

Combined power (+12V)

849.6 W

Combined power (+5V)

120 W

Combined power (-12V)

3.6 W

Combined power (+5Vsb)

15 W

Max output current (+3.3V)

22 A

Max output current (+12V1)

40 A

Max output current (+12V2)

36 A

Max output current (+5V)

22 A

Max output current (-12V)

0.3 A

Max output current (+5Vsb)

3 A

Hold time

17 ms

Efficiency

93.4 %

Power Good signal delay range

100 - 150 ms

Power protection features

Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage

Ports & interfaces

Motherboard power connector

20+4 pin ATX

Motherboard power cable length

550 mm

Number of SATA power connectors

6

Number of PATA power connectors

1

SATA power cable length

450,550,570,670,690,790 mm

Peripheral (Molex) power connectors (4-pin)

1

Peripheral (Molex) power cable length

790 mm

EPS power connector (8-pin)

Kyllä

PCI Express power connectors (6+2 pin)

4

PCI Express power cable length

650 mm

CPU power connector (4+4 pin)

Kyllä

CPU power cable length

600 mm

ATX power connector (20+4 pin)

Kyllä

PCI Express connector

Kyllä

Cabling type

Non-Modular

Performance

Purpose

PC

Power supply unit (PSU) form factor

ATX

80 PLUS certification

80 PLUS Gold

ATX version

2.52

EPS version

2.92

Noise level

30.7 dB

Bearing technology

Rifle

Mean time between failures (MTBF)

100000 h

Design

Product colour

Black

Cooling type

Active

Fan diameter

120 mm

Number of fans

1 fan(s)

Fan speed

0 - 2000 RPM

Illumination

Ei

On/off switch

Kyllä

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Storage temperature (T-T)

-20 - 70 °C

Operating relative humidity (H-H)

0 - 90 %

Storage relative humidity (H-H)

0 - 95 %

Certificates

Compliance certificates

CCC, CE, Federal Communications Commission (FCC), RoHS, WEEE

Certification

CB, TÜV, cRUus, cTUVus, RCM (Australia), BSMI, CU (Russia)

Weight & dimensions

Width

160 mm

Depth

86 mm

Height

150 mm

Weight

2140 g

Packaging data

Manual

Kyllä

Manual languages

German, English, Spanish, French, Polish, Russian

Package width

220 mm

Package depth

300 mm

Package height

100 mm

Package weight

2600 g

Technical details

Sustainability certificates

ENERGY STAR, ErP

Logistics data

Warranty period

5 year(s)

Country of origin

Germany

Other features

Screws included

Kyllä

Noise level (silent mode, <30%)

10.3 dB

Noise level (quiet mode, 50%)

10.4 dB

Noise level (full-load mode, 100%)

30.7 dB
