Synology DiskStation DS1823XS+

Tuote

Valmistaja

Synology

Tuoteperhe / -sarja

DiskStation

Tuotenimi

DS1823XS+

Valmistajan linkki

https://www.synology.com/en-global/products/DS1823xs+

Tuotekoodit

Valmistajan tuotekoodit

• DS1823XS+

GTIN- / EAN-koodit

• 4711174724956

Tuotekuvat

Storage

Storage drives installed

Ei

Total installed storage capacity

0 TB

Number of storage drives installed

0

Number of storage drives supported

8

Installed storage drive type

Ei

Supported storage drive types

HDD & SSD

Supported storage drive interfaces

Serial ATA

Storage drive sizes supported

2.5,3.5,M.2 "

Number of M.2 (M & B) slots

2

RAID support

Kyllä

RAID levels

0, 1, 5, 6, 10, JBOD

Online RAID migration

Kyllä

Online RAID expansion

Kyllä

Hot-swap drive bays

Kyllä

Supported file systems

BTRFS, Fat, HFS+, NTFS, exFAT, ext3, ext4

Processor

Processor manufacturer

AMD

Processor family

Ryzen Embedded

Processor generation

AMD Ryzen Embedded V1000 Series

Processor model

V1780B

Processor frequency

3.35 GHz

Processor boost frequency

3.6 GHz

Processor cores

4

Number of processors supported

1

Memory

Internal memory

8 GB

Internal memory type

DDR4

Maximum RAM supported

32 GB

Memory slots

2

Memory form factor

SO-DIMM

ECC

Kyllä

Network

Ethernet LAN

Kyllä

Ethernet LAN data rates

10,100,1000,10000 Mbit/s

Ethernet LAN data rate supported (max)

10000 Mbit/s

Copper ethernet cabling technology

10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T

iSCSI support

Kyllä

Supported network protocols

SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

Link aggregation

Kyllä

Ports & interfaces

Ethernet LAN (RJ-45) ports

4

USB port

Kyllä

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

3

eSATA ports quantity

2

PCI Express x8 (Gen 3.x) slots

1

Design

Chassis type

Tower

Cooling type

Active

Product colour

Black

Number of fans

2 fan(s)

Fan diameter

120 mm

LED indicators

Kyllä

Built-in display

Ei

Cable lock slot

Kyllä

Cable lock slot type

Kensington

Built-in speaker(s)

Ei

Performance

Type

NAS

Device class

Small & Medium Business

Backup function

Kyllä

Backup features

Cloud, iSCSI LUN

Multilingual support

Kyllä

Noise level

23.6 dB

Card reader integrated

Ei

Snapshot

Kyllä

Management protocols

SNMP

Security algorithms

AES

Access Control List (ACL)

Kyllä

Reset button

Kyllä

On/off switch

Kyllä

Built-in FTP server

Kyllä

Browser supported

Google Chrome Firefox Microsoft Edge Safari

System log

Kyllä

Software

Operating system installed

DiskStation Manager

Operating system version

7.1.1

Server operating systems supported

Windows Server 2019

Power

Power supply location

Built-in

Power supply unit (PSU) capacity

250 W

Number of power supply units

1

Redundant power supply (RPS) support

Ei

Power consumption (typical)

87.93 W

AC input voltage

100 - 240 V

AC input frequency

50 / 60 Hz

Weight & dimensions

Width

343 mm

Depth

243 mm

Height

166 mm

Weight

6200 g

Packaging content

Cables included

AC, LAN (RJ-45)

Power cables quantity

1

Sustainability

Sustainability compliance

Kyllä

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

5 - 95 %

Storage temperature (T-T)

-20 - 60 °C

Storage relative humidity (H-H)

5 - 95 %

Other features

Compliance certificates

CE, RoHS

Certification

FCC BSMI VCCI RCM EAC CCC KC
