APC GVSUPS50KB4GS

Tuote

Valmistaja

APC

Tuotenimi

GVSUPS50KB4GS

Valmistajan linkki

https://www.apc.com/us/en/product/GVSUPS50KB4GS/galaxy-vs-ups..

Tuotekoodit

Valmistajan tuotekoodit

• GVSUPS50KB4GS

GTIN- / EAN-koodit

• 0731304641841

Tuotekuvat

Features

UPS topology

Double-conversion (Online)

Output power capacity

50 kVA

Output power

50000 W

Waveform

Sine

Input operation voltage (max)

480 V

Input frequency

40/70 Hz

Output operation voltage (max)

480 V

Output frequency

50/60 Hz

Maximum current

74 A

Heat dissipation

5210 BTU/h

Number of input phases

3

Number of output phases

3

Input power factor

0.99

Crest factor

2.5:1

ECO mode

Kyllä

Input current Total Harmonic Distortion (THD)

3 %

Noise level

61 dB

Power protection features

Overload, Short circuit

Audible alarm(s)

Kyllä

Ports & interfaces

AC outlet types

Hard Wire 3-wire (3PH + G), Hard Wire 5-wire (3PH + N + G)

SmartSlot

Kyllä

Battery

Battery technology

Sealed Lead Acid (VRLA)

Battery voltage

480 V

Design

Form factor

Tower

Product colour

White

Display type

LCD

International Protection (IP) code

IP20

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Storage temperature (T-T)

-15 - 40 °C

Operating relative humidity (H-H)

0 - 90 %

Storage relative humidity (H-H)

10 - 80 %

Operating altitude

0 - 1000 m

Non-operating altitude

0 - 3048 m

Certificates

Certification

CSA C22.2 No 107.3, FCC Part 15 class A, IEC 62040-3, IEC 60721-4-2 Level 2M2, UL 1778 5th edition

Packaging content

Manual

Kyllä

Quick installation guide

Kyllä

Weight & dimensions

Width

521 mm

Depth

847 mm

Height

1485 mm

Weight

460000 g

Packaging data

Package width

640 mm

Package depth

990 mm

Package height

1680 mm

Package weight

490000 g
