Phanteks D30-140

Tuote

Valmistaja

Phanteks

Tuotenimi

D30-140

Valmistajan linkki

https://phanteks.com/product/d30-140-white/#Product_Select

Tuotekoodit

Valmistajan tuotekoodit

• PH-F140D30R_DRGB_PWM_WT01_3P

GTIN- / EAN-koodit

• 0886523003328

Tuotekuvat

Performance

Suitable location

Computer case

Type

Fan

Fan diameter

140 mm

Rotational speed (min)

250 RPM

Rotational speed (max)

1800 RPM

Noise level (high speed)

32.1 dB

Maximum airflow

71.76 cfm

Maximum air pressure

3.08 mmH2O

Fan 2 rotational speed (min)

250 RPM

Fan 2 rotational speed (max)

1800 RPM

Fan 2 noise level (high speed)

32.1 dB

Fan 2 maximum airflow

71.76 cfm

Fan 2 maximum air pressure

3.08 mmH2O

Bearing type

Fluid Dynamic Bearing (FDB)

Fan noise level (max)

32.1 dB

Quantity per pack

3 pc(s)

Fan speed (min)

250 RPM

Fan speed (max)

1800 RPM

Fan static pressure

3.08 mmH2O

Mean time between failures (MTBF)

50000 h

Design

Product colour

White

Number of fans

3 fan(s)

Number of fan blades

7

Illumination LED

Kyllä

Number of LEDs

30

Fan connector

4-pin

Power

Power consumption (typical)

1.8 W

Voltage

5 - 13.2 V

Fan power consumption

1.8 W

Maximum current

0.45 A

LED voltage

5 V

Fan current

0.15 A

Weight & dimensions

Width

140 mm

Depth

30 mm

Height

140 mm

Fan dimensions (W x D x H)

140 x 140 x 30 mm

Fan thickness

30 mm

Fan weight

350 g

Fan 2 dimensions (W x D x H)

140 x 140 x 30 mm

Fan 2 weight

350 g

Cable length

0.7 m

Package weight

1030 g

Technical details

Warranty period

3 year(s)

Packaging content

Package type

Box

Cables included

4-pin
