Ominaisuudet
- 80 PLUS certification
- 80 PLUS Bronze
- Hyötysuhde
- 88 %
Arvostelut
Arvostele tuoteAlin hinta 30 päivän aikana
53,49 €
+11,61 %
Hinta on nyt 6,21 € kalliimpi.
HintahistoriaTuotetiedot
Tuote
- Valmistaja
- Cooler Master
- Tuotenimi
- MWE Bronze 650 V3 230V
- Valmistajan linkki
- https://www.coolermaster.com/en-au/products/mwe-bronze-650-v3..
Tuotekoodit
- Valmistajan tuotekoodit
- MPE-6501-ACABW-3BEU
- GTIN- / EAN-koodit
- 4719512145227
Tuotekuvat
Power
- Total power
- 650 W
- AC input voltage
- 200 - 240 V
- AC input frequency
- 50/60 Hz
- Input current
- 5 A
- Power Factor Correction (PFC) type
- Active
- Combined power (+3.3V)
- 120 W
- Combined power (+12V)
- 648 W
- Combined power (+5V)
- 120 W
- Combined power (-12V)
- 3.6 W
- Combined power (+5Vsb)
- 15 W
- Max output current (+3.3V)
- 19 A
- Max output current (+12V)
- 54 A
- Max output current (+5V)
- 19 A
- Max output current (-12V)
- 0.3 A
- Max output current (+5Vsb)
- 3 A
- Hold time
- 16 ms
- Efficiency
- 88 %
- Power Good signal delay range
- 100 - 150 ms
- Power protection features
- Over power, Over voltage, Overheating, Short circuit, Under voltage
Ports & interfaces
- Motherboard power connector
- 24-pin ATX
- Motherboard power cable length
- 500 mm
- Number of SATA power connectors
- 6
- SATA power cable length
- 400,550,700 mm
- Peripheral (Molex) power connectors (4-pin)
- 3
- Peripheral (Molex) power cable length
- 550,700,400 mm
- EPS power connector (8-pin)
- Kyllä
- EPS power connector (4+4 pin)
- Kyllä
- PCI Express power connectors (6+2 pin)
- 4
- PCI Express power cable length
- 620 mm
- Cabling type
- Non-Modular
Performance
- Purpose
- PC/Server
- Power supply unit (PSU) form factor
- ATX
- 80 PLUS certification
- 80 PLUS Bronze
- ATX version
- 3.1
- Bearing technology
- HDB
- Mean time between failures (MTBF)
- 100000 h
Design
- Product colour
- Black
- Cooling type
- Active
- Fan diameter
- 120 mm
- Number of fans
- 1 fan(s)
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
Certificates
- Compliance certificates
- BIS, CE, China Compulsory Certification (CCC), EAC, Federal Communications Commission (FCC), RCM, RoHS, UKCA
- Certification
- ErP 2014 Lot 3
Weight & dimensions
- Width
- 150 mm
- Depth
- 140 mm
- Height
- 86 mm
- Weight
- 1650 g
Packaging data
- Package width
- 190 mm
- Package depth
- 245 mm
- Package height
- 110 mm
- Package weight
- 2050 g
Logistics data
- Master (outer) cases per pallet (air)
- 32 pc(s)
- Master (outer) case width
- 260 mm
- Master (outer) case length
- 570 mm
- Master (outer) case height
- 215 mm
- Products per master (outer) case
- 5 pc(s)
Other features
- EPS cable length
- 670 mm
