Gigabyte P550SS

Tuote

Valmistaja

Gigabyte

Tuotenimi

P550SS

Valmistajan linkki

https://www.gigabyte.com/

Tuotekoodit

Valmistajan tuotekoodit

• GP-P550SS EU

GTIN- / EAN-koodit

• 4719331554187

Tuotekuvat

Power

Total power

550 W

AC input voltage

155-240 V

AC input frequency

50/60 Hz

Input current

6.3 A

Power Factor Correction (PFC) type

Active

Combined power (+3.3V)

100 W

Combined power (+12V)

549.6 W

Combined power (+5V)

100 W

Combined power (-12V)

3.6 W

Combined power (+5Vsb)

15 W

Max output current (+3.3V)

20 A

Max output current (+12V)

45.8 A

Max output current (+5V)

20 A

Max output current (-12V)

0.3 A

Max output current (+5Vsb)

3 A

Hold time

16 ms

Efficiency

90 %

Power Good signal delay range

100 - 150 ms

Power protection features

Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage

Ports & interfaces

Motherboard power connector

20+4 pin ATX

Motherboard power cable length

600 mm

Number of SATA power connectors

5

Peripheral (Molex) power connectors (4-pin)

4

PCI Express power connectors (6+2 pin)

2

CPU power connector (4+4 pin)

Kyllä

ATX power connector (20+4 pin)

Kyllä

Floppy drive power connector

2

Floppy disk drive connector

Kyllä

PCI Express connector

Kyllä

Cabling type

Non-Modular

Performance

Purpose

PC

Power supply unit (PSU) form factor

ATX

80 PLUS certification

80 PLUS Silver

ATX version

3.1

Bearing technology

Ball bearing

Mean time between failures (MTBF)

100000 h

Design

Product colour

Black

Cooling type

Active

Fan diameter

120 mm

Number of fans

1 fan(s)

Fan location

Top

On/off switch

Kyllä

Weight & dimensions

Width

140 mm

Depth

150 mm

Height

86 mm

Weight

1860 g

Packaging data

Package width

254 mm

Package depth

206 mm

Package height

117 mm

Package weight

2316 g

Package type

Box

Logistics data

Warranty period

3 year(s)
