Ominaisuudet
- 80 PLUS certification
- 80 PLUS Gold
- Hyötysuhde
- 90 %
Arvostelut
Arvostele tuoteAlin hinta 30 päivän aikana
149,99 €
+12,75 %
Hinta on nyt 19,13 € kalliimpi.
HintahistoriaTuotetiedot
Tuote
- Valmistaja
- Cooler Master
- Tuotenimi
- MWE Gold 1250 V2 ATX 3.1
- Valmistajan linkki
- https://www.coolermaster.com/en-global/products/mwe-gold-1250..
Tuotekoodit
- Valmistajan tuotekoodit
- MPE-C501-AFCAG-3EEU
- GTIN- / EAN-koodit
- 4719512151204
Tuotekuvat
Power
- Total power
- 1250 W
- AC input voltage
- 100 - 240 V
- AC input frequency
- 50/60 Hz
- Input current
- 15 - 7 A
- Power Factor Correction (PFC) type
- Active
- Combined power (+3.3V)
- 120 W
- Combined power (+12V)
- 1248 W
- Combined power (+5V)
- 120 W
- Combined power (-12V)
- 3.6 W
- Combined power (+5Vsb)
- 15 W
- Max output current (+3.3V)
- 20 A
- Max output current (+12V)
- 104 A
- Max output current (-12V)
- 0.3 A
- Max output current (+5Vsb)
- 3 A
- Hold time
- 16 ms
- Efficiency
- 90 %
- Power Good signal delay range
- 100 - 150 ms
- Power protection features
- Over current, Over power, Over total voltage, Over voltage, Short circuit, Under voltage
Ports & interfaces
- Motherboard power connector
- 24-pin ATX
- Motherboard power cable length
- 650 mm
- Number of SATA power connectors
- 12
- SATA power cable length
- 500,620,740,860 mm
- Peripheral (Molex) power connectors (4-pin)
- 4
- Peripheral (Molex) power cable length
- 740,620,500,860 mm
- EPS power connector (8-pin)
- Kyllä
- EPS power connector (4+4 pin)
- Kyllä
- PCI Express power connectors (6+2 pin)
- 3
- ATX Power connector (24-pin)
- Kyllä
- Cabling type
- Fully-Modular
Performance
- Purpose
- PC
- Power supply unit (PSU) form factor
- ATX
- 80 PLUS certification
- 80 PLUS Gold
- ATX version
- 3.1
- Bearing technology
- TBB
- Mean time between failures (MTBF)
- 100000 h
Design
- Product colour
- Black
- Cooling type
- Active
- Fan diameter
- 140 mm
- Number of fans
- 1 fan(s)
- Fan location
- Top
- On/off switch
- Kyllä
Operational conditions
- Operating temperature (T-T)
- 0 - 50 °C
Certificates
- Certification
- TUV, cTUVus, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, BIS
Weight & dimensions
- Width
- 150 mm
- Depth
- 180 mm
- Height
- 86 mm
- Weight
- 3020 g
Packaging data
- Package width
- 197 mm
- Package depth
- 333 mm
- Package height
- 122 mm
- Package weight
- 3420 g
- Package type
- Box
Technical details
- Sustainability certificates
- ErP
