Axis Q8752-E Mk II Zoom 8.3 fps

Tuote

Valmistaja

Axis

Tuotenimi

Q8752-E Mk II Zoom 8.3 fps

Valmistajan linkki

https://www.axis.com/products/axis-q8752-e-mk-ii

Tuotekoodit

Valmistajan tuotekoodit

• 03050-001

Tuotekuvat

Performance

Type

IP security camera

Placement supported

Indoor & outdoor

Connectivity technology

Wired

PTZ control

Kyllä

Auto-tracking

Kyllä

Tour recording

Kyllä

Preset points

Kyllä

Thermal module

Kyllä

Wide Dynamic Range (WDR)

Kyllä

Day/night mode

Kyllä

Infrared (IR) cut-off filter

Kyllä

Thermal sensitivity (NETD)

50 mK

Certification

UL/cUL, CE, KC, VCCI, RCM

Design

Form factor

Box

Product colour

Black, White

Housing material

Aluminium, Glass, Thermoplastic

International Protection (IP) code

IP66

IK code

IK10

Fog proof

Kyllä

Camera

Minimum illumination

0.01 lx

Vertical field of view (thermal module)

13.5 °

Horizontal field of view (thermal module)

18 °

Lens viewing angle, horizontal

58.5 °

Lens viewing angle, vertical

35 °

Tilt angle range

-90 - 45 °

Tilt speed

65 °/sec

Pan range

0 - 360 °

Pan speed

120 °/sec

Camera shutter speed

1/66500 - 2 s

Number of Privacy masking areas

32

Image sensor

Sensor type

CMOS

Number of sensors

1

Optical sensor size

1/2.8 "

Effective sensor resolution (thermal module)

640 x 480 pixels

Progressive scan

Kyllä

Lens system

Number of lenses

1

Zoom capability

Kyllä

Optical zoom

32 x

Digital zoom

12 x

Focal length range

4.3 - 137.6 mm

Auto focus

Kyllä

Maximum aperture number

4

Minimum aperture number

1.4

Closest focusing distance

7 m

Aperture number (thermal module)

1.6

Video

Maximum resolution

1920 x 1080 pixels

Video formats supported

AVC, H.264, H.265, HEVC, M-JPEG, MPEG4

Frame rate

60 fps

Video streaming

Kyllä

Image quality adjustment

Brightness, Contrast, Saturation, Sharpness

Text caption overlay

Kyllä

Image stabilizer

Kyllä

Bit rate control

Variable Bit Rate (VBR)

Audio

Audio system

1-way

Audio formats supported

AAC-LC, ADPCM, G.711, G.726, LPCM, OPUS, PCM

Audio detection

Kyllä

Sample rates

8 - 48 kHz

Network

Ethernet LAN

Kyllä

Ethernet interface type

Fast Ethernet, Gigabit Ethernet

Networking standards

IEEE 802.1AE, IEEE 802.1x

Supported network protocols

IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS , HTTP/ 2, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/ DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)

Storage

Compatible memory cards

MicroSD (TransFlash), MicroSDHC, MicroSDXC

Flash memory

512 MB

Internal memory

2000 MB

Ports & interfaces

Microphone in

Kyllä

Terminal block port

Kyllä

Security

Video motion detection

Kyllä

Privacy protection

Kyllä

Pixel counter

Kyllä

Power

Power source type

DC

Power consumption (typical)

25 W

Power consumption (max)

185 W

Operational conditions

Operating temperature (T-T)

-40 - 60 °C

Storage temperature (T-T)

-40 - 65 °C

Operating relative humidity (H-H)

10 - 100 %

Storage relative humidity (H-H)

5 - 95 %

Weight & dimensions

Width

229 mm

Depth

360 mm

Height

581 mm

Weight

15300 g

Sustainability

Compliance certificates

REACH, RoHS, Trade Agreements Act (TAA)

Packaging content

Number of cameras

1

Manual

Kyllä

Wiper included

Kyllä

Other features

Doesn't contain

PVC
