MSI MODERN AM242 1M-1219EU

Tuote

Valmistaja

MSI

Tuoteperhe / -sarja

Modern AM242

Tuotenimi

MODERN AM242 1M-1219EU

Valmistajan linkki

https://www.msi.com/All-in-One-PC/Modern-AM242-1MX/Overview

Tuotekoodit

Valmistajan tuotekoodit

• MODERN AM242 1M-1219EU

GTIN- / EAN-koodit

• 4711377232036

Tuotekuvat

Display

Display diagonal

23.8 "

Display resolution

1920 x 1080 pixels

Touchscreen

Ei

HD type

Full HD

Display brightness

250 cd/m²

Panel type

IPS

Pixel pitch

0.2745 x 0.2745 mm

Anti-glare screen

Kyllä

Low Blue Light technology

Kyllä

Tilt adjustment

Kyllä

Tilt angle range

-5 - 15 °

Number of external displays supported

1

Processor

Processor manufacturer

Intel

Processor family

Intel Core 5

Processor generation

Intel Core (Series 1)

Processor model

120U

Processor cores

10

Processor threads

12

Processor boost frequency

5 GHz

Performance cores

2

Efficient cores

8

Performance-core Max Turbo Frequency

5 GHz

Efficient-core Max Turbo Frequency

3.8 GHz

Performance-core base frequency

1.4 GHz

Efficient-core base frequency

0.9 GHz

Processor cache

12 MB

Processor cache type

Smart Cache

Processor base power

15 W

Maximum turbo power

55 W

Memory

Internal memory

8 GB

Internal memory type

DDR5-SDRAM

Maximum internal memory

64 GB

Memory slots

2

Memory slots type

SO-DIMM

Memory clock speed

5600 MHz

Memory layout (slots x size)

1 x 8 GB

Memory form factor

DIMM/SO-DIMM

Storage

Total storage capacity

512 GB

Storage media

SSD

Total SSDs capacity

512 GB

Number of SSDs installed

1

SSD capacity

512 GB

NVMe

Kyllä

SSD form factor

M.2

M.2 SSD size

2280 (22 x 80 mm)

Optical drive type

Ei

Graphics

Discrete graphics card

Ei

Discrete graphics card model

Not available

On-board graphics card

Kyllä

On-board GPU manufacturer

Intel

On-board graphics card family

Intel® Graphics

On-board graphics card model

Intel® Graphics

Audio

Built-in speaker(s)

Kyllä

Number of speakers

2

RMS rated power

5 W

Audio chip

Realtek ALC256

Camera

Built-in camera

Kyllä

Camera HD type

Full HD

Network

Wi-Fi

Kyllä

Top Wi-Fi standard

Wi-Fi 6E (802.11ax)

Wi-Fi standards

Wi-Fi 6E (802.11ax)

WLAN controller manufacturer

Intel

WLAN controller model

Intel Wi-Fi 6E AX211

Ethernet LAN

Kyllä

Bluetooth

Kyllä

Bluetooth version

5.3

Ports & interfaces

Ethernet LAN (RJ-45) ports

1

USB 2.0 ports quantity

2

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

0

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity

0

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

2

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity

2

USB4 Gen 3x2 ports quantity

0

HDMI ports quantity

2

Microphone in

Kyllä

Combo headphone/mic port

Kyllä

Number of rear USB ports

2

Number of side USB ports

4

Design

Product colour

Black

Height adjustment

Ei

Cable lock slot

Kyllä

Cable lock slot type

Kensington

VESA mounting

Kyllä

Panel mounting interface

75 x 75 mm

Performance

Product type

All-in-One PC

Market positioning

Business

Motherboard chipset

Intel SoC

Software

Operating system installed

Windows 11 Pro

Power

AC adapter power

120 W

Weight & dimensions

Package width

631 mm

Package depth

170 mm

Package height

493 mm

Operational conditions

Operating temperature (T-T)

0 - 35 °C

Storage temperature (T-T)

-20 - 60 °C

Operating relative humidity (H-H)

0 - 85 %

Storage relative humidity (H-H)

0 - 90 %

Certificates

Certification

FCC, CB/CE, UL & CUL, VCCI, RCM

Other features

Warranty period

2 year(s)
