Shuttle Slim PC DN11H5

Tuote

Valmistaja

Shuttle

Tuotenimi

Slim PC DN11H5

Valmistajan linkki

https://www.shuttle.eu/en/products/slim/dn11h5

Tuotekoodit

Valmistajan tuotekoodit

• DN11H5

GTIN- / EAN-koodit

• 0887993007298

Tuotekuvat

Processor

Built-in processor

Kyllä

Processor manufacturer

Intel

Processor family

Intel Core Ultra 5

Processor generation

Intel® Core™ Ultra (Series 1)

Processor model

125H

Processor cores

14

Processor threads

18

Processor boost frequency

4.5 GHz

Performance cores

4

Efficient cores

8

Performance-core Max Turbo Frequency

4.5 GHz

Efficient-core Max Turbo Frequency

3.6 GHz

Low Power Efficient-core Max Turbo Frequency

2.5 GHz

Performance-core base frequency

1.2 GHz

Efficient-core base frequency

0.7 GHz

Low Power Efficient-core Base Frequency

700 MHz

Processor cache

18 MB

Memory

Memory slots type

SO-DIMM

Number of memory slots

2

Maximum internal memory

96 GB

Supported memory clock speeds

5600 MHz

Supported memory types

DDR5-SDRAM

Memory channels

Dual-channel

Memory voltage

1.1 V

ECC

Ei

Non-ECC

Kyllä

Storage

Supported storage drive types

SSD

Storage drive sizes supported

M.2 "

SSD form factor

M.2

Storage drive interface

PCI Express

NVMe

Kyllä

Number of storage drives supported

3

Graphics

On-board graphics card

Kyllä

Graphics card family

Intel

On-board graphics card model

Intel Arc Graphics

Maximum resolution

3840 x 2160 pixels

Number of displays supported

4

Performance

Motherboard chipset

Intel SoC

BIOS type

UEFI AMI

Trusted Platform Module (TPM)

Kyllä

Trusted Platform Module (TPM) version

2.0

Audio chip

Realtek ALC888S

Audio

Built-in speaker(s)

Ei

Network

Ethernet LAN

Kyllä

Wi-Fi

Ei

LAN controller

Intel I226-LM

Ports & interfaces

USB 2.0 ports quantity

0

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

0

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

6

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity

2

HDMI ports quantity

2

HDMI version

2.1

VGA (D-Sub) ports quantity

0

DisplayPorts quantity

2

DisplayPort version

1.4

Microphone in

Kyllä

Headphone outputs

1

Ethernet LAN (RJ-45) ports

4

DC-in jack

Kyllä

Design

Chassis type

1.35L sized PC

Product colour

Black

Cooling type

Active

Housing material

Metal

Cable lock slot

Kyllä

Cable lock slot type

Kensington

VESA mounting

Kyllä

Panel mounting interface

75 x 75,100 x 100 mm

Product type

Mini PC barebone

Technical details

Compliance certificates

BSMI, CE, Federal Communications Commission (FCC), RoHS, cTUVus

Logistics data

Harmonized System (HS) code

84733080

Software

Windows operating systems supported

Windows 11 x64

Linux operating systems supported

Kyllä

Sustainability

Sustainability certificates

ENERGY STAR, ErP

Power

Power supply type

External AC adapter

Power supply

120 W

Number of power supply units

1

AC input voltage

100 - 240 V

AC input frequency

50/60 Hz

AC adapter output voltage

19 V

AC adapter output current

6.32 A

Operational conditions

Operating temperature (T-T)

0 - 50 °C

Operating relative humidity (H-H)

10 - 90 %

Weight & dimensions

Width

190 mm

Depth

165 mm

Height

43 mm

Weight

1230 g

Package weight

2460 g

Packaging content

Power cord included

Kyllä

AC adapter included

Kyllä

Quick start guide

Kyllä
