Ominaisuudet
- 80 PLUS certification
- 80 PLUS Gold
- Hyötysuhde
- 90 %
Arvostelut
Arvostele tuoteAlin hinta 30 päivän aikana
78,90 €
-13,94 %
Hinta on nyt 11 € halvempi.
HintahistoriaTuotetiedot
Tuote
- Valmistaja
- Cooler Master
- Tuotenimi
- MWE GOLD 850 V3
- Valmistajan linkki
- https://www.coolermaster.com/
Tuotekoodit
- Valmistajan tuotekoodit
- MPE-8506-ACAG-BEU
- GTIN- / EAN-koodit
- 4719512153437
Tuotekuvat
Power
- Total power
- 850 W
- AC input voltage
- 100 - 240 V
- AC input frequency
- 50/60 Hz
- Input current
- 6 - 10 A
- Power Factor Correction (PFC) type
- Active
- Combined power (+3.3V)
- 100 W
- Combined power (+12V)
- 849.6 W
- Combined power (+5V)
- 100 W
- Combined power (-12V)
- 3.6 W
- Combined power (+5Vsb)
- 15 W
- Max output current (+3.3V)
- 20 A
- Max output current (+12V)
- 70.8 A
- Max output current (+5V)
- 20 A
- Max output current (-12V)
- 0.3 A
- Max output current (+5Vsb)
- 3 A
- Hold time
- 16 ms
- Efficiency
- 90 %
- Power Good signal delay range
- 100 - 150 ms
- Power protection features
- Over current, Over power, Over total voltage, Over voltage, Short circuit, Under voltage
Ports & interfaces
- Motherboard power connector
- 24-pin ATX
- Motherboard power cable length
- 550 mm
- Number of SATA power connectors
- 6
- SATA power cable length
- 400,550,700 mm
- Peripheral (Molex) power connectors (4-pin)
- 3
- Peripheral (Molex) power cable length
- 400,550,700 mm
- EPS power connector (8-pin)
- Kyllä
- EPS power connector (4+4 pin)
- Kyllä
- PCI Express power connectors (6+2 pin)
- 4
- ATX Power connector (24-pin)
- Kyllä
- Number of EPS connectors
- 2
- Cabling type
- Non-Modular
Performance
- Purpose
- PC
- Power supply unit (PSU) form factor
- ATX
- 80 PLUS certification
- 80 PLUS Gold
- ATX version
- 3.1
- Bearing technology
- HDB
- Mean time between failures (MTBF)
- 100000 h
Design
- Product colour
- Black
- Cooling type
- Active
- Fan diameter
- 120 mm
- Number of fans
- 1 fan(s)
- Fan location
- Top
- On/off switch
- Kyllä
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
Certificates
- Compliance certificates
- BIS, BSMI, CCC, CE, EAC, Federal Communications Commission (FCC), RCM, TÜV mark, UKCA, cTUVus
Weight & dimensions
- Width
- 140 mm
- Depth
- 150 mm
- Height
- 86 mm
- Weight
- 1800 g
Packaging data
- Package width
- 190 mm
- Package depth
- 110 mm
- Package height
- 260 mm
- Package weight
- 2210 g
- Package type
- Box
- Case or master carton dimensions (W x D x H)
- 275 x 215 x 570 mm
Technical details
- Sustainability certificates
- ErP
