Chieftec Vega PPG-1000-C

Tuote

Valmistaja

Chieftec

Tuoteperhe / -sarja

Vega

Tuotenimi

PPG-1000-C

Tuotekoodit

Valmistajan tuotekoodit

• PPG-1000-C

GTIN- / EAN-koodit

• 0753263079091

Tuotekuvat

Power

Total power

1000 W

AC input voltage

100 - 240 V

AC input frequency

50/60 Hz

Input current

12 A

Combined power (+3.3V)

100 W

Combined power (+12V)

1000 W

Combined power (+5V)

100 W

Combined power (-12V)

3.6 W

Combined power (+5Vsb)

15 W

Max output current (+3.3V)

20 A

Max output current (+12V)

83.33 A

Max output current (+5V)

20 A

Max output current (-12V)

0.3 A

Max output current (+5Vsb)

3 A

Power protection features

Over current, Over voltage, Overload, Short circuit, Surge and inrush

Ports & interfaces

Motherboard power connector

24-pin ATX

Motherboard power cable length

600 mm

Number of SATA power connectors

6

SATA power cable length

150,400 mm

Peripheral (Molex) power connectors (4-pin)

3

Peripheral (Molex) power cable length

150,400 mm

EPS power connector (8-pin)

Kyllä

EPS power connector (4+4 pin)

Kyllä

PCI Express power connectors (6+2 pin)

4

PCI Express power connectors (12+4 pin)

1

PCI Express power connectors (12+4 pin) cable length

600 mm

PCI Express power cable length

600 mm

CPU power connector (4+4 pin)

Kyllä

CPU power cable length

650 mm

ATX Power connector (24-pin)

Kyllä

PCI Express connector

Kyllä

Number of EPS connectors

2

Cabling type

Fully-Modular

Performance

Purpose

PC

Power supply unit (PSU) form factor

ATX

80 PLUS certification

80 PLUS Gold

ATX version

3.1

Bearing technology

FDB

Design

Product colour

White

Cooling type

Active

Fan diameter

135 mm

Illumination

Ei

Certificates

Certification

80PLUS Gold

Weight & dimensions

Width

150 mm

Depth

150 mm

Height

85 mm
