DELL PowerEdge R760XS

Tuote

Valmistaja

DELL

Tuoteperhe / -sarja

PowerEdge

Tuotenimi

R760XS

Valmistajan linkki

https://www.dell.com/en-uk/shop/ipovw/poweredge-r760xs

Tuotekoodit

Valmistajan tuotekoodit

• FFCWR

GTIN- / EAN-koodit

• 5397184980583

Tuotekuvat

Processor

Processor manufacturer

Intel

Processor family

Intel Xeon Silver

Processor model

4510

Processor frequency

2.4 GHz

Processor boost frequency

4.1 GHz

Processor cores

12

Processor cache

30 MB

Motherboard chipset

Intel C741

Number of processors installed

1

Thermal Design Power (TDP)

150 W

System bus rate

16 GT/s

Processor threads

24

Memory types supported by processor

DDR5-SDRAM

Memory clock speeds supported by processor

4400 MHz

Memory

Internal memory

32 GB

Internal memory type

DDR5-SDRAM

Buffered memory type

Registered (buffered)

Memory ranking

2

Memory slots

16x DIMM

Memory layout (slots x size)

1 x 32 GB

Memory data transfer rate

5600 MT/s

Maximum internal memory

1000 GB

Storage

Total storage capacity

480 GB

Number of SSDs installed

1

SSD capacity

480 GB

SSD interface

SATA III

SSD size

2.5"

Supported SSD sizes

3.5"

Number of SSDs supported

8

Supported RAID controllers

Front PERC H755 Front Loadd

Hot-Plug support

Kyllä

Optical drive type

Ei

Drive writes per day (DWPD)

1

Storage drive adapter included

Kyllä

Storage drive adapter type

2.5" - 3.5"

Network

LAN controller

Broadcom 5720

Ethernet LAN

Kyllä

Cabling technology

10/100/1000Base-T(X)

Ethernet interface type

Gigabit Ethernet

Ports & interfaces

Ethernet LAN (RJ-45) ports

2

USB 2.0 ports quantity

2

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

1

VGA (D-Sub) ports quantity

2

Expansion slots

PCI Express x8 slots

1

PCI Express x16 slots

1

Design

Chassis type

Rack (2U)

Product colour

Black

Rack rails

Kyllä

Bezel

Kyllä

Performance

Remote administration

iDRAC9, Enterprise 16G,Dual

Software

Operating system installed

Ei

Compatible operating systems

Canonical Ubuntu Server LTS Microsoft Windows Server with Hyper-V Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware vSAN/ESXi

Power

Redundant power supply (RPS) support

Kyllä

Power supply

1100 W

Number of redundant power supplies installed

2

Power supply input voltage

100-240 V

Operational conditions

Storage temperature (T-T)

-40 - 65 °C

Storage relative humidity (H-H)

5 - 95 %

Operating altitude

0 - 3048 m

Non-operating altitude

0 - 12000 m

Certificates

80 PLUS certification

80 PLUS Titanium

Carbon footprint

Total carbon footprint (kg of CO2e)

6654

Total carbon emissions, standard deviation (kg of CO2e)

3747

Carbon emissions, manufacturing (kg of CO2e)

465.78

Carbon emissions, logistics (kg of CO2e)

133.08

Carbon emissions, energy usage (kg of CO2e)

6055.14

Carbon emissions, end-of-life (kg of CO2e)

0

PAIA version

PAIA 1.3.2, 2022

Weight & dimensions

Width

482 mm

Height

86.8 mm

Packaging content

Packaging content

ReadyRails Sliding Rails With Cable Management Arm,Riser Config 0 2x Rack Power Cord 2M (C13/C14 12A) - FGA Only

Other features

Data transfer rate

6 Gbit/s

Bytes per sector

512e

Target workload

Read Intensive (RI)

RAID controller type

Unconfigured RAID for HDDs or SSDs (Mixed Drive Types Allowed)

Open Compute Project (OCP)

NIC 3.0
