Seasonic PRIME Fanless TX

Tuote

Valmistaja

Seasonic

Tuoteperhe / -sarja

Prime

Tuotenimi

PRIME Fanless TX

Valmistajan linkki

https://seasonic.com/prime-fanless-tx/

Tuotekoodit

Valmistajan tuotekoodit

• SSR-700TL

Tuotekuvat

Power

Total power

700 W

AC input voltage

100 - 240 V

AC input frequency

50/60 Hz

Input current

9, 4.5 A

Combined power (+3.3V)

100 W

Combined power (+12V)

696 W

Combined power (-12V)

3.6 W

Combined power (+5Vsb)

15 W

Max output current (+3.3V)

20 A

Max output current (+12V2)

58 A

Max output current (+5V)

20 A

Max output current (-12V)

0.3 A

Max output current (+5Vsb)

3 A

Efficiency

94 %

Power protection features

Overheating, Over current, Over power, Under voltage, Over voltage, Short circuit

Ports & interfaces

Motherboard power connector

20+4 pin ATX

Motherboard power cable length

610 mm

Number of SATA power connectors

10

SATA power cable length

450,810,860 mm

Peripheral (Molex) power connectors (4-pin)

5

Peripheral (Molex) power cable length

470,690 mm

PCI Express power connectors (6+2 pin)

1

PCI Express power cable length

750 mm

CPU power connector (4+4 pin)

Kyllä

CPU power cable length

650 mm

Cabling type

Fully-Modular

Performance

Purpose

PC

Power supply unit (PSU) form factor

ATX

80 PLUS certification

80 PLUS Titanium

Mean time between failures (MTBF)

100000 h

Design

Product colour

Grey

Cooling type

Passive

On/off switch

Kyllä

Operational conditions

Operating temperature (T-T)

0 - 45 °C

Packaging content

Cables included

AC, CPU, PCIe, Peripheral (Molex), Peripheral (Molex) to SATA 3.3, SATA

Certificates

Compliance certificates

REACH, RoHS, WEEE

Weight & dimensions

Width

170 mm

Depth

150 mm

Height

86 mm

Technical details

Sustainability certificates

ENERGY STAR
