ASUS Zenbook S16 UM5606GA-SR334W

Tuote

Valmistaja

ASUS

Tuoteperhe / -sarja

Zenbook S16

Tuotenimi

UM5606GA-SR334W

Valmistajan linkki

https://www.asus.com/laptops/for-home/zenbook/asus-zenbook-s-1..

Tuotekoodit

Valmistajan tuotekoodit

• 90NB17H4-M00H90

GTIN- / EAN-koodit

• 4711636378963

Tuotekuvat

Design

Product type

Laptop

Product colour

White

Colour name

3W, Scandinavian White

Form factor

Clamshell

Housing material

Aluminium

Market positioning

Home

Display

Display diagonal

16 "

Display resolution

2880 x 1800 pixels

Touchscreen

Kyllä

HD type

3K

Panel type

OLED

Display number of colours

1.07 billion colours

Native aspect ratio

16:10

Display surface

Gloss

Display brightness

500 cd/m²

Maximum display brightness (HDR)

1000 cd/m²

RGB colour space

DCI-P3

Colour gamut

100 %

Low Blue Light technology

Kyllä

Display response rise/fall

0.2 ms

Maximum refresh rate

120 Hz

Contrast ratio (typical)

1000000:1

High Dynamic Range (HDR) supported

Kyllä

High Dynamic Range (HDR) technology

DisplayHDR True Black 1000

Processor

Processor manufacturer

AMD

Processor family

AMD Ryzen AI 9

Processor generation

AMD Ryzen AI 400 Series

Processor model

465

Processor cores

10

Processor threads

20

Processor boost frequency

5 GHz

Processor frequency

2 GHz

Processor cache type

L2 & L3

L3 cache

24 MB

L2 cache

10 MB

Neural processor unit (NPU)

Copilot+ PC

Kyllä

Neural processor unit (NPU)

AMD Ryzen AI

Total processor performance up to

73 TOPs

NPU performance up to

50 TOPs

Memory

Internal memory

32 GB

Internal memory type

LPDDR5x-SDRAM

Memory form factor

On-board

Maximum internal memory

32 GB

Storage

Total storage capacity

1000 GB

Storage media

SSD

Total SSDs capacity

1000 GB

Number of SSDs installed

1

SSD capacity

1000 GB

SSD interface

PCI Express 4.0

NVMe

Kyllä

SSD form factor

M.2

M.2 SSD size

2280 (22 x 80 mm)

Optical drive type

Ei

Card reader integrated

Kyllä

Compatible memory cards

SD

Graphics

On-board graphics card

Kyllä

Discrete graphics card

Ei

Discrete graphics card model

Not available

On-board GPU manufacturer

AMD

On-board graphics card family

AMD Radeon

On-board graphics card model

AMD Radeon Graphics

On-board graphics card 4K support

Kyllä

On-board graphics card 8K support

Kyllä

AMD FreeSync

Kyllä

Audio

Audio system

Smart Amp

Built-in microphone

Kyllä

Camera

Front camera

Kyllä

Front camera resolution

1920 x 1080 pixels

Front camera HD type

Full HD

Infrared (IR) camera

Kyllä

Network

Mobile network connection

Ei

Wi-Fi

Kyllä

Top Wi-Fi standard

Wi-Fi 7 (802.11be)

Wi-Fi standards

Wi-Fi 7 (802.11be)

Antenna type

2x2

Bluetooth

Kyllä

Bluetooth version

5.4

Ports & interfaces

USB 2.0 ports quantity

0

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

0

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity

0

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

1

USB4 Gen 3x2 ports quantity

2

HDMI ports quantity

1

HDMI version

2.1

Combo headphone/mic port

Kyllä

USB Type-C DisplayPort Alternate Mode

Kyllä

I/O ports

1x USB 3.2 Gen 2 Type-A (data speed up to 10Gbps)\n2x USB 4.0 Gen 3 Type-C with support for display / power delivery (data speed up to 40Gbps), 1x HDMI 2.1 TMDS\n1x 3.5mm Combo Audio Jack, SD 4.0 card reader

Keyboard

Pointing device

Touchpad

Numeric keypad

Ei

Keyboard backlit

Kyllä

Copilot key

Kyllä

Software

Operating system installed

Windows 11 Home

Operating system architecture

64-bit

Microsoft Copilot

Kyllä

Pre-installed software

StoryCube\nASUS Recovery\nMyASUS\nScreenXpert\nGlideX

Trial software

1-month trial for new Microsoft 365 customers. Credit card required.

Bundled software

Xbox Game Pass Premium_2 months (*Terms and exclusions apply. Offer only available in eligible markets for Xbox Game Pass Premium. Eligible markets are determined at activation. Game catalog varies by region, device, and time.)

Battery

Battery technology

Lithium-Ion (Li-Ion)

Number of battery cells

4

Battery capacity

83 Wh

Power

USB Type-C charging port

Kyllä

USB Type-C required charging power (min)

45 W

USB Type-C required charging power (max)

65 W

USB Power Delivery (USB PD)

Kyllä

Security

Windows Hello

Kyllä

Trusted Platform Module (TPM)

Kyllä

Certificates

Compliance certificates

RoHS, REACH

Certification

US MIL-STD 810H

Sustainability

Sustainability certificates

ENERGY STAR

Weight & dimensions

Weight

1500 g

Width

353.6 mm

Depth

243 mm

Height (front)

11.9 mm

Height (rear)

12.9 mm

Packaging content

AC adapter included

Ei

Bag included

Kyllä

Accessories included

Sleeve, * Included accessories vary according to country and territory. Please check with your local ASUS retailer for details.

Other features

Expansion slots

1x M.2 2280 PCIe 4.0x4
