Newstar FPMA-D700D3

Tuote

Valmistaja

Newstar

Tuotenimi

FPMA-D700D3

Valmistajan linkki

https://www.neomounts.com/default.asp?pageid=44&artdetail..

Tuotekoodit

Valmistajan tuotekoodit

• FPMA-D700D3

GTIN- / EAN-koodit

• 5054484394396
• 8717371443641

Tuotekuvat

Mounting

Number of displays supported

3

Maximum weight capacity (per display)

8 kg

Maximum weight capacity

8 kg

Minimum screen size

10 "

Maximum screen size

27 "

Mounting type

Desk

Mounting

Clamp

Minimum VESA mount

75 x 75 mm

Maximum VESA mount

100 x 100 mm

Panel mounting interface

100 x 100,75 x 75 mm

Desk thickness (max)

90 mm

Distance to the wall (min)

0 mm

Distance to the wall (max)

70 mm

Ergonomics

Height adjustment

Kyllä

Height adjustment type

Manual

Height adjustment range

320 - 420 mm

Depth adjustment range

0 - 70 mm

Width adjustment

1225 mm

Tilt angle range

-90 - 90 °

Swivelling

Kyllä

Swivel angle

103 °

Swivel angle range

0 - 103 °

Rotating

Kyllä

Angle of rotation

360 °

Design

Product colour

Black

Housing material

Steel

Weight & dimensions

Width

1225 mm

Depth

70 mm

Height

420 mm

Weight

9160 g

Packaging data

Package width

750 mm

Package depth

334 mm

Package height

160 mm

Package weight

9500 g

Other features

Width adjustment range

0 - 1225 mm

Logistics data

Master (outer) case width

750 mm

Master (outer) case length

334 mm

Master (outer) case height

160 mm

Master (outer) case gross weight

10500 g

Products per master (outer) case

1 pc(s)

Country of origin

Taiwan

Master (outer) case net weight

9500 g

Harmonized System (HS) code

7326909890

Products per pallet (EU)

39 pc(s)
